Description
Overall Size: 72” x 144”
Max Glass Size: 70 1/2” x 141 ½”
Glass thickness : 4.7 mm – 19 mm or 3/16” – ¾”
Minimum glass size : 300 mm x 200 mm or 11 ¾” x 8”
Production: 5 mm float glass 15-16 batch /H
Power consumption : 5 mm float glass about 3.5 kwh/qm
Under continuous production with 80% loading efficiency
Installed Power: (480V 60HZ 3P )
Heating Chamber : 540 KW
Blower Power : 75 KW
Driving Motor : 7.4 KW
Recommended Transformer 400KVA
Suitable Glass Types:
Clear float glass
Tinted Float glass
Low-E Glass
Low iron Glass
Single side screen printed glass
Figured glass
Normal Coated glass
Included Equipment:
Loading/unloading table: transmission roller, lifting table, transmission drive system
Heating section: heating and driving system
Cooling system: Cooling and driving system
Air supply and valve
High pressure blower
Pneumatic control system(Not including air supply)
Electric control system
Standard spare parts
UPS（10KVA)
Unloading roller device
22KW Air compressor
Fully cover
