AMERICAN 84″ Stainless Steel Horizontal Glass Washer



Technical Specification:

• Variable Speed up to 26 FPM (Faster speeds are possible)
• Glass Thickness: 0-3/4″
• Minimum glass size: 8″x 16″
• Modular and User Friendly
• Stainless Steel Wash, Rinse and Dryer sections
• Heavy Duty Aluminum Frame Support
• Exterior Conveyor Supports are Powder Coated
• Stainless Steel Pre-Wash Section
• Low-E Glass Brushes
• Specially Designed Air Knives
• 25HP High Pressure Blower
• Line Drive Conveyor
• 4 Post Screw Jack Lift Top Up to 14” Max Height
• Digital Display for Glass Thickness Easily Adjusted
• Water Lines & Electric Lines are Quick Disconnect
• Washer is set up for DI water
• Independent and Movable Stainless Steel Water Tanks
• Thermostat Controlled Immersion Water Heater
• Low Water Level Safety Switch
• Electrics According to Customer specifications: 480V, 3Phase, 60Hz


Size Dimensions Weight KW
84″ 17’x10’x9′ 10,000lbs 24


This stainless steel glass washing machine is suitable for different thicknesses of glass 0-3/4in. Cleaning and drying is automatic; horizontal transmission; 6 brushes; 4 special air knives for drying, temperature control, variable speed conveyor. Glass thickness digitally controlled by 4 screw jack lift top. Glass comes out dry without the need to run the glass at an angle.


Call us with any questions: 814-807-4545
